Marine Technical Internship Blog

Week 6:

Monday kicked off the Navy’s inspection visit. They were on site for most of the week, though I didn’t interact with them much directly. I continued to spend the majority of my time helping out the mechs. Unfortunately, I don’t have any photos from this week because my phone’s camera was damaged the week before.

One of the first tasks I helped with was preparing for the inspection of the 12” and 17” viewport windows for the sphere. This meant cleaning out the back end of a shipping container that’s used as a workshop, so the windows would be protected during inspection. After clearing out tools and parts, we scrubbed all surfaces, edges, corners, ceiling, etc to knock loose anything that might fall later. We vacuumed up the debris, blew the area out with compressed air, and finished by covering the counter with cloth pads to create a cushioned base. Work in the clean area paused at that point since the actual window inspections were delayed.

Tuesday was spent continuing window prep. After the team performs a visual inspection to check for obvious defects, the windows are sent out for more detailed inspection using a non-contact coordinate measuring machine, lasers. To safely ship and store the windows when they’re not installed in the sphere, the team uses Pelican and other branded rugged protective cases. While the spare windows were already stored in padded cases, there weren’t enough cases for all the windows being removed, and not all the existing cases matched in size, which made stacking messy. I was tasked with finding enough correctly sized cases to store both the in-service and spare windows. Fortunately, the Alvin team has a stash of empty rugged cases for situations like this. After a lot of digging, I found the right quantities in each size. I then padded each case to securely hold the conical windows. For foam being transferred between cases, I trimmed or added padding as needed. In one instance, I used a bandsaw to make clean, tapered cuts in a large piece of custom foam so it fit perfectly in its new case, was a beautiful fit.

On Wednesday, I shifted focus to inspecting the Alvin “skins.” These are carbon fiber and HDPE panels that protect certain areas of the sub and help with hydrodynamics. There are around 25 skins total, ranging from relatively flat, square panels to highly complex curved shapes. I checked them for damage, but my main responsibility was verifying the dimensions of all features. Over time, these skins can be modified for fit or function, and it was my job to identify any deviations from the official engineering drawings. Working closely with both shore-side and seagoing engineers, I produced redline engineering drawings documenting all changes. This took up most of the rest of the week and carried into the following one.

Thursday marked the end of the Navy’s visit, which sounded like it went smoothly overall. After work, we had the NDSF (National Deep Submergence Facility) department Christmas party, where I got to meet a lot of great people from the ROV Jason and AUV Sentry teams.

Friday wrapped up the week on a high note with the larger WHOI Christmas party in the evening.

Week 7:

Monday was a continuation of skin inspections. The skins were a constant presence throughout the week, and I returned to them each day whenever other tasks did not take priority.

On Tuesday, I was back assisting with the visual inspections of the viewport windows. Removing a window from the sub is a coordinated process that requires three people. Two remove the bolts securing the retaining ring, while a third supports the window using a large suction cup.

Once the retaining ring is off and the window finally releases from its tapered seat (often the most challenging part) the window is carefully carried to the cleaned bench space for inspection. All surfaces are thoroughly wiped down, followed by an even more detailed inspection for any signs of damage. The entire cleaning and inspection process is observed by a second person, who signs off to verify everything was completed correctly.

After the visual inspections, the windows were packed into their shipping cases for further evaluation. The original manufactured dimensions of each window are well known, which allows them to be measured using a Coordinate Measuring Machine (CMM). This inspection is non-contact and uses lasers to scan the window’s geometry, creating a highly accurate 3D model. The data is then compared to the original specifications to check for distortion, shrinkage, or other subtle changes that wouldn’t be visible to the eye.

Wednesday involved a trip to the warehouse to pick up a large quantity of syntactic foam buoyancy blocks. Several of the buoyancy foam components on Alvin have damaged sections, and these blocks are sent out along with the larger pieces so repair shops have matching material to work with

Thursday’s highlight was a lunch-and-learn session presented by Danik, one of Alvin’s pilots and the Training Coordinator. The talk, titled “Red Hat vs. Blue Hat Thinking,” focused on how to train for emergencies and high-stress situations aboard a ship. It covered strategies for preparing ahead of time, managing emotions in the moment, and responding effectively when things don’t go as planned.

Then came glorious Friday, the skins were finally conquered. I handed off the last of the redline drawings to the engineering team and wrapped up the week with a relatively relaxing task: printing and binding a large stack of Oxygen Worker Safety Training manuals. These manuals cover procedures for preventing contamination and other issues while inspecting and maintaining oxygen-related life support systems, problems that could otherwise lead to system failure or, more seriously, fire or explosion.

Week 3:

Monday continued the inspections of the motor-controller pods. There are four pods in total: two units that control four motors each and two units that control two. The main purpose of these visual inspections is to verify the condition of the housings as part of a larger inspection of all implodable volumes. While inspecting the pods, we noticed damaged wiring and took the opportunity to repair it while the pods were already open.

It was my first time working with Molex Micro-Fit connectors, a fairly standard connector, but also my first time working with silver-tinned, Teflon-insulated wire. Compared to other jacket types, the Teflon insulation presents a new to me challenge; it’s so slippery that inserting the pins into the connectors requires more care and patience.

Motor-pod inspections continued through the end of Wednesday. No major flaws were found in the housings. We did, however, bring out and learn to use the optical micrometer to verify that a few worrisome scratches were below the maximum allowed depth of 0.005″. The deepest we found was around 0.002″, well within tolerance.

Thursday and Friday were spent working down the list of other implodable components. The highlight of the week came on Friday with the mech team’s removal of the sphere. After days of preparation and planning, followed by a morning of discussion, the team spent about an hour and some change performing a slow, methodical sequence of bolt removal and lifting the sphere onto its temporary stand.

Week 4:

This was a short week due to the Thanksgiving holiday. Monday and Tuesday were spent continuing the inspection of the remaining implodable volumes, with no concerning flaws found in any of the equipment.

The big event of the week was the retirement party for Lane Abrams, a Senior Electrical Engineer who has been part of the Alvin team for 34 years.

Week 5:

Monday and Tuesday turned into paperwork-heavy days. Many parts and consumables connected to or used in testing critical systems require verified histories so their material quality can be tracked. Many of the tools used on these systems must also be calibrated by certified labs. We received several shipments of calibrated tools and materials, and I spent time checking every page of the accompanying reports, verifying that correct procedures were followed, materials met the required specifications, and all serial, order, and reference numbers matched across every document. I also checked stock levels for components and made lists of cables/wires that may be replaced during the overhaul.

On Wednesday and Thursday, I began helping out the mech team. Our first task was cleaning and inspecting the variable ballast spheres. These are four titanium spheres, roughly 2 feet in diameter, that are used to adjust Alvin’s buoyancy. Following standard procedures, we rinsed each sphere with fresh water for a set amount of time. This took a while, since each sphere requires the crane for moving, and managing the water flow took some planning to avoid turning the shop into a pond.

Next, we set up the spheres for visual inspection. The process was similar to the inspections performed on the smaller implodable volumes: cleaning the spheres, buffing any scratches that drew attention, and, if a scratch still looked questionable, using the optical micrometer to confirm it was within acceptable depth. No concerning flaws were found. The main difference with these spheres was the internal inspection. Each sphere has only two openings, each about half an inch wide, located at the top and bottom. Inspecting the interior required using a borescope, which turned out to be an interesting exercise involving a bit of a dance around the spheres to see every angle we needed to check.

Thursday night marked the third session of our team’s D&D campaign, and I’d been, mostly in secret, putting together a costume for my druid. The highlight was an oak staff topped with a quartz crystal, illuminated from within by a bright LED I could control by wireless remote. The reveal was a hit, and now it sounds like a couple others are planning to bring costume pieces next week.

Friday was spent cleaning the shop and preparing for next week. The Navy will be visiting for the majority of the week to conduct an inspection.

Since this is a long-term internship running through nearly the end of May, I will be providing updates roughly every two weeks.

The Alvin team is an amazing group and has been welcoming at every step. I am housing with Wren (mech engineer) and Randy (expedition leader). During the first weekend, they made sure I was settled into our housing and fully prepared for our first day. I work alongside the sea-going operations half of the team for much of the regular workday, where my endless, excited questions are always welcomed and answered. I also regularly spend time with the shore-based team during lunch, enjoying stories and getting to know the entire group. I will primarily be working with the electrical engineering team during the overhaul, but I also hope to spend time with the mechanical engineers when possible.

Day one started off slowly, as nearly the entire Alvin group and a few other WHOI personnel gathered in an auditorium for the first half of the day for a presentation and discussion on how the next seven-plus months will proceed. Meticulous planning has clearly gone into ensuring the overhaul goes as smoothly as possible. After a generous lunch of pizza, we headed to WHOI’s Smith Laboratory High Bay to meet the Alvin and begin our hands-on work.

Alvin on day 1

Week one quickly gained momentum as the electrical and mechanical teams continued the disassembly of Alvin, which had partially begun before all team members arrived in Woods Hole. My own start was a bit slower, as I spent much of the first week completing on-boarding training and other administrative requirements. Fortunately, I still had time to assist with disassembly occasionally.

During the removal of one of the syntactic foam blocks, which provide buoyancy, I noticed tiny cracks in the bend radius of a bracket. The bracket was tagged for later review by the mech team to determine whether it would need to be re-fabricated. I also assisted with the crane lift of the wiring harness from inside the sphere and transporting it to the birdcage. The birdcage is a replica of the framework inside the sphere, providing a way to manage equipment and wiring during testing of the sphere’s electronics. One of this weeks most important discoveries was the very important WHOI tradition of office dogs. There are so many, and they are all friendly and loving, truly great for morale.

Week two continued with disassembly. Much of the work involved straightforward manual tasks, such as disconnecting and pulling the dozens of cables from their pathways snaking throughout the vessel, then coiling them up at the junction boxes. Once each j-box was completely free of its tethered connections, we removed it so the mech team would have full access to the components they handle.

A major highlight of the week was the first session of our overhaul DnD campaign. Multiple team members met up Thursday night for character creation and planning. If the first session is any indication of the campaign ahead, there will be no shortage of laughter.

On Friday, Ben (a new electrical engineer) and I began visual inspections of the motor controllers. These are titanium pods that contain a motor driver and a WHOI designed supervisor board. The inspection process involves disassembling and cleaning the titanium housings to inspect for damage, replacing o-rings, and checking the cable fittings for signs of wear. A slow and purposeful procedure that will continue into next week. With full testing of the electrical components happening at a later stage of the overhaul. Though Rick (senior electrical engineer) was able to provide us a lesson on how the motor controllers function, how the supervisor boards cleverly manage the motor controllers when the pods are fully sealed during normal operation, and a bit of history on how and why the current versions differ from the older designs.

Two stellar weeks down and 27ish more to go. I’m excited for all the fascinating things I’ll continue learn throughout this internship and for the opportunity to keep working with such amazing people.

Hello everyone!

My name is Ken and I will be an intern assisting with the upcoming routine overhaul of the HOV Alvin for the next 7 months.

I’m a undergraduate robotics student and most recently built a USV for mapping small lakes, pictured below. I have some experience with boats and ships, previously sailing aboard the Sea Education Association’s (SEA) Corwith Cramer and Robert C Seamans as an engineer. But this will be my first time working with a submersible.

I have dreamed of working with Alvin for many years and am very excited for this opportunity. Tomorrow I drive down to Woods Hole, MA and early next week I meet the Alvin Team and begin my internship.
